500*1000Mm full color led screen rental or fixed installation die casting aluminum

Brand Name : BST

Model Number : BST-IR3

Certification : CE,FCC, CCC, Rohs,ISO

Place of Origin : China

MOQ : 1sqm / Piece

Price : Negotiation

Payment Terms : T/T, Western Union, L/C

Supply Ability : 5000sqm per month

Delivery Time : 7 - 20 days

Packaging Details : wooden case

Power Supply : AC 110/220V

Display Function : HD Video,Image

Scan Mode : 1/16 scan

Brightness : 1200nits /sqm

Pixel Per Cabinet : 32768

Color : Full Color

LED Lamp : SMD2121

Contact Now

500*1000Mm full color led screen rental or fixed installation die casting aluminum

Products Feature

1.· Durable, reliable, precisely made Aluminum die-casting, fanless design Small expansion coefficient
2. Spring locks connect the cabinets vertically, hanging max 15 cabinets in a line;
3. Well-performing High contrast louver design with rain channel,Light tight design, no blocks on the image
BST processing with Radiant Calibration System
4. Macromolecular flexible mask with glareless surface and better contrast ratio;
5.· Slim .Perfect rounding off for 3m radius convex curve
6. Signal and power indicator & reset button well shows the working condition
of the whole screen;
7. Fast spring locks connect the cabinets horizontally, only 10 seconds for per
cabinet;
8. Light-weight 28kg/sq.m. for panel with light-weight sub-frame structure design
9. Nanotechnology and unique positioning system, making the installation and
dismantlement in one step;
10. BST robust electronics design

Specification:

BST-IR3mm Spec

Pixel Pitch (mm)

3.91

LED Type

SMD2121

Pixel Density (pixel/sq.m.)

65536

Viewing Angle (H/V)

140° / 140°

Brightness(cd/sq.m.)

1200

Refresh Rate(Hz)

1920~4800

Optimized Viewing Distance (m)

3~30

Average Power Consumption (W/sq.m.)

272

Max. Power Consumption (W/sq.m.)

680

Input Voltage

AC110V or AC220V±10% 50/60Hz

Module Size in Pixel (W×H)

64×64

Module Size in mm (W×H)

250×250

Panel Size in Pixel (W×H)

128×256

Panel Size in mm (W×H×D)

500×1000×75

Weight (kg/Panel.)

IP Rating

IP43

Maintenance

Rear

Operating Temperature

-10℃ ~40℃

Operating Humidity

10~80RH%

P3.91mm indoor full color LED Display

500*1000Mm full color led screen rental or fixed installation die casting aluminum

500*1000Mm full color led screen rental or fixed installation die casting aluminum

Controller connection

Packing and shipment

Applications:

various applications such as broadcasting studios, control rooms, command centers, monitoring centers, pavilions, conference rooms and etc.

500*1000Mm full color led screen rental or fixed installation die casting aluminum
